The Adtech 400504 is a component module designed for integration within the ADTECH AX/4000 Portable Broadband Test System. This unit functions as part of a comprehensive broadband testing platform and powers on with operational display capability. The module weighs 22 kg and ships at a total volume weight of 36 kg within approximate dimensions of 60 × 75 × 40 cm.
Technical Specifications
• Part Number: 400504
• Parent System: ADTECH AX/4000 Portable Broadband Test System
• Unit Weight: 22 kg
• Total Volume Weight: 36 kg
• Shipping Dimensions (Approximate): 60 × 75 × 40 cm
• Related Analyzer Module: 155V2 Analyzer Board Adtech 11590 Rev A
• Operational Status: Powers on; display functional
– Key Features
• Modular integration within the AX/4000 test platform
• Compact, portable form factor optimized for field deployment
• Direct compatibility with 155V2 analyzer boards for signal analysis
– Operating Environment
The Adtech 400504 operates within a specified temperature range of 0°C to 60°C. Installation requires protection from overheating, humidity, dust, and corrosive environments. Vibration isolation via rubber rail mounting is recommended. Grounding resistance must not exceed 4 ohms for proper system operation.
– Compatibility & Integration
