The Adtech 403100-403103 is a 10 Gbps generator/analyzer module designed for network testing and analysis applications. This component integrates into larger test and measurement systems to deliver precise traffic generation and protocol analysis at high data rates. Built for reliable operation in controlled laboratory and field environments, the module supports standard grounding requirements and straightforward integration into compatible test platforms.
Technical Specifications
• Data Rate: 10 Gbps
• Product Type: Generator/Analyzer Module
• Operating Temperature: 0°C to 60°C ambient
• Grounding Requirement: Less than 4 ohms resistance; neutral line cannot serve as ground
– Key Features
• Dual-function generation and analysis capability at 10 Gbps line rates
• Modular architecture for integration into multi-slot test chassis
• Proper grounding methodology ensures electrical safety and measurement integrity
• Operating range suitable for standard laboratory conditions
– Maintenance & Handling
• Power must be disconnected before component replacement or internal service
• Minimum 1-minute interval required between power-off and re-energization
• Fault conditions—including short circuit or overload events—must be diagnosed before restart
• Enclosure must remain sealed during normal operation
• Environmental protection required: prevent dust and powder ingress
• Vibration isolation recommended in high-vibration installations
• Thermal management via auxiliary cooling may be necessary if ambient temperature approaches maximum operating limits
– Compatibility & Integration
This module is designed to interface with Adtech and compatible Spirent test platforms. System integration requires proper electrical installation with grounding resistance verification and correct wiring practices. The module operates within defined thermal and environmental parameters; installations in non-standard conditions may require additional protective measures such as vibration dampening or heat dissipation provisions.
