The Anritsu K240C is a precision resistive power divider engineered for DC to 40 GHz signal distribution in laboratory and production test environments. This 2-way divider employs a symmetrical, three-resistor tee topology to achieve accurate power division and combination across demanding frequency ranges. Built on 50 Ohm impedance with K Type connectors, the K240C delivers controlled insertion loss and exceptional amplitude and phase balance for applications requiring critical signal integrity.
Technical Specifications
• Frequency Range: DC to 40 GHz
• Configuration: 2-Way Resistive Power Divider
• Impedance: 50 Ohms
• Insertion Loss: 7 to 8.5 dB (8.5 dB maximum)
• Amplitude Balance: ±0.6 dB
• Phase Balance: ±6 Degrees
• Return Loss (Input): 11 to 20.1 dB
• Return Loss (Output): 11 to 20.1 dB
• VSWR: 1.79
• Maximum Input Power: 1 W
• Operating Temperature: 0 to 70°C
• Storage Temperature: -55 to 125°C
• Weight: 43 g
• RoHS Compliant: Yes
– Key Features
• Symmetrical three-resistor tee design enables bidirectional operation for both division and combination modes
• K Type female connectors with compatibility to GPC 3.5 and SMA adapters
• Controlled amplitude and phase balance specifications ensure predictable multi-signal distribution
• Stable performance across full DC to 40 GHz band with minimal frequency-dependent variation
• Compact, lightweight module format suitable for rack and benchtop integration
– Typical Applications
• Test and measurement instrumentation requiring accurate signal splitting
• Multi-channel laboratory measurement setups
• Production testing environments demanding repeatable power distribution
• Signal combining in composite test scenarios
– Compatibility & Integration
K Type connectors support direct interface with GPC 3.5 and SMA connector systems via passive adapters. The 50 Ohm characteristic impedance aligns with standard RF test infrastructure.
