IFR 57202 Communication Test Set CPU Board

The Cobham/Aeroflex/IFR 57202 CPU Board is a processing component designed for use within the IFR FM/AM-1200S and FM/AM-1200A Communications Service Monitors. These service monitors are multi-function, microprocessor-controlled instruments designed for radio maintenance applications, covering a frequency range from 250 kHz to 1 GHz. The 57202 CPU Board provides the essential processing power and control functions for these systems, ensuring reliable and efficient operation in industrial and aerospace environments. ### Technical Specifications * **Manufacturer:** Cobham / Aeroflex / IFR
* **Product Type:** CPU Board
* **Model:** 57202
* **Primary Application:** Control and processing for IFR FM/AM-1200S and FM/AM-1200A Communications Service Monitors
* **System Frequency Range (of associated instruments):** 250 kHz to 1 GHz
* **Form Factor:** Component-level board designed for integration into larger systems
* **Component Identification:** Identified as the CPU Board for the specified service monitors ### System Integration and Compatibility * **System Compatibility:** Specifically designed for integration with the IFR FM/AM-1200S and FM/AM-1200A Communications Service Monitors.
* **Interfacing:** Assumed to interface with other boards within the service monitor chassis, such as analog boards, RF modules, and power supply units, via internal bus structures.
* **Maintenance Considerations:** When shipping PC boards for repair, they must be packaged in a conductive bag and placed in a well-protected container to prevent electrostatic discharge (ESD) damage. Maintenance procedures require adherence to safety precautions, especially concerning high voltage potentials. ### Electrical and Physical Characteristics * **Power Requirements:** Specific voltage and current requirements are not detailed in publicly available datasheets. However, as a component within a larger instrument, it would receive regulated power from the instrument’s power supply unit.
* **Connectors:** Specific connector types and pinouts are not detailed in readily available documentation. Integration would depend on proprietary connectors or bus systems within the IFR service monitors.
* **Environmental Considerations:** Specific operating temperature, humidity, or shock and vibration ratings are not provided. However, the associated service monitors are described as “fully portable,” suggesting a degree of robustness. ### Legacy and Support * **End-of-Life (EOL):** The Cobham/Aeroflex/IFR 57202 CPU Board may be available for purchase and support from third-party suppliers beyond its End-of-Life (EOL) by the original manufacturer.
* **Documentation:** Manuals and datasheets for the associated IFR FM/AM-1200S/A instruments, which would contain relevant information about the CPU board’s operation within the system, are available. Why Choose Aumictech for the Cobham / Aeroflex / IFR 57202 CPU Board?
At Aumictech, we specialize in supplying high-end industrial and aerospace electronic components. Whether you need a critical CPU board for legacy test equipment, reliable spare parts for system maintenance, or components for integration into specialized applications, our team ensures the Cobham / Aeroflex / IFR 57202 CPU Board delivers maximum performance and longevity for your operational requirements.
