The GGB Industries Picoprobe 7-175 Replacement Probe Tip Set (2 pieces) delivers precision tungsten probe elements engineered for active probing on GGB Picoprobe Model 7 and 7A systems. Each tip features a 175 micron shaft diameter with a sub-5.0 micron point radius, enabling contact at fine geometries across high-frequency and DC measurement applications. The tips are malleable, allowing custom bending to accommodate diverse probing geometries and micropositioner configurations.
## Technical Specifications
• **Manufacturer:** GGB Industries / Picoprobe
• **Model:** 7-175
• **Quantity per Set:** 2 probe tips
• **Material:** Tungsten probing wire
• **Shaft Diameter:** 175 microns
• **Point Radius:** < 5.0 microns
• **Shielding:** Coaxial shield extends to within 3 mm of probe point
## Key Features
• Malleable construction permits bending to various probe geometries
• Coaxial probe tips, field-replaceable on compatible systems
• Minimal capacitive coupling through shielded geometry
• Compatible with any standard micropositioner
• Supports both 50 ohm terminated and unterminated probe configurations
## Typical Applications
These replacement tips enable signal acquisition across DC to 3.5 GHz when extended 0.120 inches beyond the coaxial tip (Model 7 probe). The 7-175 set serves high-frequency RF measurements, capacitance and resistance characterization, and low to medium-speed signal applications where unterminated probe operation is required.
## Compatibility & Integration
Designed exclusively for GGB Picoprobe Model 7 (50 ohm terminated, DC–3.5 GHz) and Model 7A (unterminated, low–medium speed) active probes. Both probe models supply flexible coaxial cable assemblies—6 feet standard on Model 7A, with 3-foot cable recommended for capacitance measurements. Mount directly to any micropositioner for integration with existing test infrastructure.
