The JDS Uniphase OAB1552+1FP0 is an Erbium-Doped Fiber Amplifier (EDFA) module engineered for telecommunications and data center applications across the C-band. Operating in the 1528–1565 nm wavelength range, this unit boosts optical signal power to extend transmission distances and enhance network performance. It supports deployment as a pre-amplifier, booster, or in-line amplifier in single-channel and multichannel (DWDM) systems. The compact benchtop form factor integrates easily into both laboratory and rack-mountable environments.
## Technical Specifications
• **Amplifier Type:** Erbium-Doped Fiber Amplifier (EDFA)
• **Operating Wavelength Range:** 1528–1565 nm (C-band)
• **Saturated Output Power:** 17 dBm minimum (booster configuration)
• **Noise Figure:** 4.5 dB maximum (booster configuration)
• **Small Signal Gain:** 20–24 dB minimum (booster configuration); 37 dB (pre-amplifier configuration)
• **Amplifier Configurations:** Pre-amplifier, booster, in-line amplifier
## Key Features
• Optical connectors: FC/PC, FC/APC, SC/PC, or SC/APC
• LCD display for real-time monitoring of input/output power and current
• RS232 remote control interface
• Compact dimensions: 21.2 × 8.9 × 35.5 cm (W × H × D)
• Weight: Less than 4 kg
• Operating temperature: 0–50 °C; storage: −40–70 °C
• Maximum humidity: 95% RH non-condensing (0–45 °C)
• Laser safety: FDA 21 CFR 1040.10 Class IIIb compliant (maximum output ≤24.5 dBm)
• Certifications: CE, cULus; standards compliance with UL3101-1 and CAN/CSA-C22.2 No. 1010.1
## Typical Applications
• Pre-amplifier configurations for weak signal recovery
• Booster amplifier stages for power elevation
• In-line amplifier deployment in long-haul and metropolitan networks
• Single-channel and DWDM system integration
## Compatibility & Integration
The OAB1552+1FP0 accepts single-channel and multichannel (DWDM) optical inputs across the C-band. Standard fiber connectors ensure compatibility with existing telecommunications infrastructure. The integrated LCD and RS232 control enable straightforward laboratory and field deployment.
