The Rohde & Schwarz ZV-Z34 is a mechanical calibration kit engineered to eliminate systematic errors in network analyzer measurements across RF and microwave frequencies. This standard calibration ensemble delivers traceable Short, Open, Load, and Through standards rated to 40 GHz, enabling precise vector network analyzer characterization in 50 Ω systems. The kit interfaces via 2.92 mm connectors and serves as the foundational calibration solution for broadband S-parameter acquisition.
Technical Specifications
• Frequency Range: DC to 40 GHz
• Characteristic Impedance: 50 Ω
• Connector Interface: 2.92 mm
• Calibration Standards: Short, Open, Load, Through
– Key Features
• Four-standard SOLT configuration eliminates common systematic measurement errors across the full frequency band
• 2.92 mm connectors provide mechanical repeatability and broadband performance to 40 GHz
• 50 Ω impedance matching ensures compatibility with standard RF test configurations
• Mechanical construction enables multiple measurement cycles without degradation
– Typical Applications
• Vector network analyzer calibration and verification
• S-parameter measurement error correction
• RF and microwave component characterization
• High-frequency transmission line and filter assessment
• On-wafer and component-level device testing
– Compatibility & Integration
Designed specifically for Rohde & Schwarz ZVK series network analyzers. The kit provides the primary calibration reference for frequency ranges extending to 40 GHz, enabling full dynamic range operation across these instruments.
