The WTC Binder 300°C Max Temp 1Ph Oven with Shelf is a single-phase laboratory and industrial oven engineered for precise thermal processing up to 300°C (572°F). Built on Binder’s APT.line™ preheating chamber technology, this unit delivers uniform temperature distribution and reproducible results across drying, sterilization, and aging test applications. Microprocessor control with digital LCD display manages temperature settings with precision, while Class 2 independent temperature safety devices with visual alarm protect against overshoot conditions.
Technical Specifications
• Maximum Temperature: 300°C (572°F)
• Control System: Microprocessor-controlled with digital LCD display
• Convection: Forced convection for rapid heating and uniform temperature distribution
• Interior: Stainless steel construction for corrosion resistance
• Insulation: High-quality thermal insulation minimizing energy loss
• Safety Device: Class 2 independent adjustable temperature safety device (DIN 12880) with visual alarm; Class 3.1 models available with visual/acoustic alarms
• Electrical Phase: Single-phase (1Ph)
• Nominal Voltage: 120V or 230V ±10% (region-dependent)
• Frequency: 50/60 Hz
• Nominal Current: 7.0 A (230V) / 10.5 A (115V) typical
• Nominal Power: 0.8 kW (120V) / 2.7 kW (230V) typical
• Timer Functions: Time-segment, real-time, ramp, delayed off, and delayed on programming
• Ventilation Control: Program-controlled exhaust air flap with adjustable front ventilation option
• Racks: Chrome-plated racks supplied with unit
• Stackability: Units supported up to 115 L capacity for space-efficient installation
– Key Features
• APT.line™ preheating chamber technology ensures temperature accuracy and reproducibility under full load
• Energy consumption optimized to 30% below conventional units
• Corrosion-resistant stainless steel interior simplifies cleaning and maintenance
• Comprehensive timer programming for complex thermal cycles
– Typical Applications
• Material drying and moisture removal
• Thermal aging and degradation testing
• Heat sterilization processes
• Component bake-out procedures
– Compatibility & Integration
• RS 422 interface for data logging and system integration
• USB port available on select models for data recording
• Ethernet interface available on select models
