The Advantest R3264 is a spectrum analyzer operating from 9 kHz to 3.5 GHz, engineered for signal analysis in laboratory and field environments. It delivers dynamic range of 70 dB or better and typical noise performance of -146 dBm/Hz at 2 GHz, making it suitable for EMC measurements, component testing, and communication system validation. The R3264 combines high-resolution analysis with practical measurement functions including ACP, occupied bandwidth, harmonics, and phase noise characterization.
Technical Specifications
Frequency Coverage: 9 kHz to 3.5 GHz
Resolution Bandwidth: 1 Hz to 10 MHz analog; digital RBW from 1 Hz to 100 Hz
Dynamic Range: 70 dB or better at 5 MHz offset (W-CDMA ACP); -145 dBc/Hz typical at 2 GHz
Noise Floor: -146 dBm/Hz typical at 2 GHz
Input Attenuator: 0 to 75 dB in 5 dB steps
1 dB Gain Compression: 0 dBm typical (±3 dBm)
Signal Purity: -110 dBc/Hz at 10 kHz offset; -90 dBc or less two-signal 3rd-order intermodulation (2 GHz band)
Frequency Response Flatness: ±1.5 dB in-band (9 kHz to 3.5 GHz); ±3.0 dB with 30 MHz calibration reference
Span Accuracy: ±0.2% typical; ±1% or better specification
Display: 6.5-inch TFT color LCD
Trace Update Rate: Up to 20 times/sec; 1 µs fast zero-span sweep
– Key Features
• Adjacent channel leakage power and occupied bandwidth measurements
• SSB phase noise and phase jitter automatic measurement
• Harmonics, spurious emission, and code domain power analysis
• Inter-modulation distortion measurement and 3rd-order characterization
• Modulation accuracy and waveform quality assessment
• 1 Hz resolution frequency counter
• Limit test function with PASS/FAIL judgment
• 2-trace simultaneous display and delayed/gated sweep functions
• Peak list and XdB down measurement capabilities
– Measurement Functions
Channel and total power, AM percentage measurement, noise per Hertz analysis, and Tx power measurement with high stability.
– Compatibility & Integration
GPIB, RS-232, parallel, and VGA interfaces enable system integration. 3.5-inch MS-DOS compatible floppy storage; optional memory card drive available. Rated for altitude to 2000 m, Installation Category II, Pollution Degree 2.
