The Agilent/Keysight 04339-65006 is a shunt connector assembly designed for precision adjustment and calibration procedures on the Agilent 4339B High Resistance Meter. This component establishes the critical ground and guard signal paths required during voltage source adjustment operations and EEPROM calibration updates. The connector interfaces directly with the 4339B’s Ground and Guard terminals, enabling accurate voltage source adjustment data configuration and system troubleshooting.
Technical Specifications
• Rated for operation with 4339B systems handling up to 1000 Vdc maximum input voltage (when High Voltage indicator is active)
• Direct connection to Ground and Guard measurement terminals
– Key Features
• Dedicated shunt configuration for voltage source adjustment procedures
• Enables EEPROM calibration data updates on the 4339B platform
• Supports performance verification and system troubleshooting workflows
• Maintains signal integrity between Ground and Guard measurement paths
– Typical Applications
• Voltage source adjustment calibration on Agilent 4339B High Resistance Meters
• System troubleshooting and performance verification
• EEPROM programming and calibration data management
• High-voltage measurement system maintenance and adjustment
– Compatibility & Integration
• Agilent 4339B High Resistance Meter
• Agilent V Measurement Adapter (PN 04339-65006)
• Agilent 3458A Multimeter integration
