The Agilent/Keysight 08640-67002 is an RF power amplifier module engineered for the 8640A and 8640B signal generators. This output amplifier assembly extends the signal generation capability to 18 GHz, serving as either a replacement component or integral subsystem within the host instrument.
Technical Specifications
• Product Type: Power Amplifier Module
• Frequency Range: Up to 18 GHz
• Function: Output Amplifier
• Part Number: 08640-67002
– Key Features
The 08640-67002 module integrates directly into compatible Agilent/Keysight signal generators as a dedicated RF power amplification stage. Its internal design handles the full frequency spectrum up to 18 GHz without requiring external tuning or reconfiguration. The module operates as part of the signal generator’s output chain, amplifying modulated and unmodulated signals across the supported frequency band.
– Compatibility & Integration
The 08640-67002 is designed for direct installation and operation with the following signal generators:
• Agilent/Keysight 8640A
• Agilent/Keysight 8640B
The module mounts internally within the instrument chassis. Installation and electrical integration conform to the mechanical and interface specifications of these signal generator platforms. Replacement availability for this legacy component is maintained through authorized Keysight service centers and specialized test equipment distributors. For parts inquiries, contact Keysight Technologies at 800-829-4444 or usa_orders@keysight.com.
