The Agilent/Keysight 10441B is a 10:1 miniature passive probe engineered for precision signal measurements across DC to 500 MHz. Its modular construction enables individual replacement of probe tips, cables, and chassis assemblies, minimizing repair costs and system downtime. The probe’s narrow, sharp tip excels at probing surface mount technology and fine-pitch geometries without compromising measurement integrity.
Technical Specifications
• Attenuation Ratio: 10:1
• Bandwidth: DC to 500 MHz
• Input Impedance: 1 MΩ
• Input Capacitance: 9.0 pF or 9.5 pF
• Circuit Loading: 1 MΩ; 9.0 pF
• Cable Length: 2 meters
• Maximum Input Voltage: 500 V RMS (CAT I and CAT II)
• Connector Type: BNC
• Weight: Approximately 65 grams
• Compensation Range: 7 pF to 25 pF
– Key Features
• Probe identification pin enables automatic oscilloscope recognition and setup on compatible instruments
• Ferrite bead ground lead reduces high-frequency noise in sensitive measurements
• General-purpose grabber and IC grabber (0.1-inch pitch compatible) prevent adjacent pin shorting
• Barrel insulator protects probe tip and circuitry from unintended contact
• Four grounding spanners support high-frequency measurement techniques
• Eight colored cable markers simplify multi-probe setups and documentation
– Typical Applications
• Surface mount technology (SMT) circuit probing and validation
• High-speed digital signal integrity measurements
• IC pin-level diagnostics and troubleshooting
• General-purpose analog and mixed-signal circuit characterization
– Compatibility & Integration
Designed for oscilloscopes with 1 MΩ input impedance and probe ID recognition capability. Typical scope bandwidth of 500 MHz aligns with probe bandwidth for optimal measurement performance. The BNC connector and identification pin support seamless integration with Agilent oscilloscope platforms featuring automatic probe detection.
