The Agilent/Keysight 10475A is a 1.8V logic-level clock pod engineered for pattern generation and digital test applications. It connects to the 16720A and 1670G-004 pattern generators, providing clock distribution with programmable output delay and high-frequency switching capability. Each pattern generator requires a minimum of one clock pod; up to four data pods can be supported per generator. The 10475A delivers clock outputs via 74AVC16244 drivers and accepts both clock and pattern inputs at rates up to 200 MHz. Integration requires the Agilent 10498A lead set.
Technical Specifications
Clock Output
• Driver type: 74AVC16244
• Maximum output rate: 200 MHz
• Output delay: Adjustable across 14 steps, approximately 8 ns total
Clock Input
• Input type: 74AVC16244 (3.6 V maximum)
• Input rate: DC to 200 MHz
• Input to output delay: Approximately 30 ns
Pattern Input
• Input type: 74AVC16244 (3.6 V maximum; no connect = 0)
• Input rate: DC to 200 MHz
• Input to recognition delay: Approximately 15 ns + 1 clock period
Logic Level Support
• Operating voltage: 1.8V
– Key Features
• Programmable output delay in 14 discrete steps for timing optimization
• DC to 200 MHz clock input and pattern input capability
• Approximately 30 ns clock-in to clock-out propagation delay
• 3.6 V maximum input tolerance on clock and pattern inputs
• Single lead set requirement per pod for streamlined integration
– Compatibility & Integration
The 10475A is compatible with Agilent Technologies’ 16720A and 1670G-004 pattern generators. Each clock pod requires one Agilent 10498A lead set for connection to the pattern generator header.
