The Agilent/Keysight 44709A is a 20-channel FET multiplexer terminal block engineered for signal routing in test and measurement applications. Built on field-effect transistor switching technology, this component delivers precise signal multiplexing within the 447xx series platform. The 44709A integrates directly into larger test systems as a dedicated signal-switching module, offering terminal block connectivity for straightforward wiring integration.
Technical Specifications
• Manufacturer: Agilent / HP / Keysight
• Model: 44709A
• Product Type: 20-Channel FET Multiplexer Terminal Block
• Channel Count: 20 channels
• Series: 447xx Series FET Multiplexers
• Switching Technology: Field-Effect Transistor (FET)
• Interface: Terminal block configuration
• Weight: 15 lbs
– Key Features
• 20-channel architecture for multi-signal routing
• FET-based switching for reliable signal multiplexing
• Terminal block interface for direct signal connections
• Part of a modular 447xx series platform offering 20, 24, and 48-channel variants
• Related configurations include standard, single-ended, and high-speed types available across the series
– Typical Applications
• Automated test and measurement signal routing
• Multi-channel signal switching in instrumentation systems
• Data acquisition and signal conditioning modules
• Laboratory and production test environments requiring flexible signal multiplexing
– Compatibility & Integration
