The Agilent/Keysight 5086-7604 is a 50 GHz doubler module engineered for integration into Agilent/Keysight signal generation and measurement systems. This frequency multiplication component doubles input signals to produce 50 GHz outputs, supporting advanced RF and microwave applications requiring precise frequency extension.
Technical Specifications
• Operating Frequency: 50 GHz doubler
• Weight: 0.477 kg
– Key Features
• Dedicated frequency doubling to 50 GHz
• Compact module form factor
• Designed for direct integration with compatible Agilent/Keysight platforms
– Typical Applications
• RF and microwave signal generation systems
• Frequency extension and multiplication in test and measurement
• High-frequency signal sourcing and analysis
– Compatibility & Integration
The 5086-7604 integrates directly with the Agilent/Keysight 83650A, 83650B, and 83650L synthesizer series. The module is also associated with the 85106D and 85301B systems. A refurbished equivalent model, the 5086-6604, provides a cost-optimized alternative for applications where new units are not required. Integration requires compatible host equipment; consult specific system documentation for installation and operating requirements.
