The Agilent/Keysight E1463A is a C-size, single-slot VXI switch module delivering 32 Form C (SPDT) channels with 5 Amp per-channel current handling. Register-based control enables rapid switching for power distribution, process control, and appliance test sequences. The module’s sub-3 µV typical thermal offset voltage qualifies it for precision signal-switching and scanning applications where low noise is critical. Non-latching relays maintain a defined state upon power loss. Connection is via QUIC screw terminal block; optional solder eye connectors are available. The main board accommodates user-installed series and shunt protection elements—MOVs, fuses, signal conditioning circuits—providing flexibility for harsh or sensitive environments.
Technical Specifications
• Module Type: VXI Switch Module, C-size, 1-slot
• Register-Based Architecture: Yes
• Channel Count: 32
• Channel Configuration: Form C (SPDT)
• Current Rating: 5 Amp per channel
• Thermal Offset Voltage: Less than 3 µV typical
• Relay Type: Non-latching
– Key Features
• High current capacity supports demanding power-switching loads up to 5 Amps
• Low thermal offset enables measurement-grade signal routing without offset nulling
• QUIC screw terminal block for direct field wiring
• Optional solder eye connectors for PCB integration
• On-board provisions for series and shunt circuit protection and signal conditioning
• Non-latching relay design ensures safe, predictable idle state
– Typical Applications
• Power distribution and on/off control in manufacturing automation
• Appliance and device pass/fail testing
• Process control switching matrices
• Low-level analog signal scanning and multiplexing
• Sensor and transducer measurement networks
– Compatibility & Integration
• VXIbus register-based architecture with SCPI command support
• VXI plug&play driver availability
• Mounts in any standard VXI mainframe
• User documentation and service manuals available
