The AMTI A-320 is a six-axis force plate engineered for high-precision biomechanical research and clinical applications. It measures three force components (Fx, Fy, Fz) and their corresponding moments (Mx, My, Mz) with high sensitivity and minimal crosstalk. This capability enables detailed analysis of human and animal movement across gait analysis, sports performance assessment, balance studies, and rehabilitation research. The A-320 delivers low crosstalk, excellent repeatability, and proven long-term stability across demanding laboratory environments.
Technical Specifications
• Measurement Axes: Six axes (3 Forces, 3 Moments)
• Crosstalk: Less than 2% on all channels
• Hysteresis (Fx, Fy, Fz): ± 0.2% Full Scale Output
• Non-linearity (Fx, Fy, Fz): ± 0.2% Full Scale Output
• Excitation: 10V maximum
• Operating Temperature: 0 to 125°F (-17 to 52°C)
– Key Features
• High sensitivity across all measurement axes
• Minimal signal crosstalk ensures measurement fidelity
• Tight hysteresis and non-linearity specifications support repeatable, accurate data acquisition
• Recommended use with AMTI amplifier for optimal signal conditioning
– Typical Applications
• Gait analysis and walking mechanics studies
• Balance and postural stability testing
• Sports biomechanics and athletic performance assessment
• Rehabilitation and clinical movement research
• Animal locomotion analysis
– Compatibility & Integration
Integrates with AMTI Optima series amplifiers via standard 30-foot force plate-to-amplifier cable. Compatible with AMTI Gen 5 and AMTI Optima amplifiers for motion capture system integration. Requires 10V maximum excitation source.
