The Ando AQ5524B is an optical monitor that converts optical signals into electrical outputs for characterization and testing within optical communication systems. It operates at dual telecommunications wavelengths and delivers a high-speed electrical signal suitable for further analysis and measurement of optical signal parameters in telecommunications and data communication test environments.
Technical Specifications
• Input Wavelengths: 1.3 µm and 1.55 µm
• Maximum Input Power: +3 dB
• Output Bit Rate: 2.4 GB/s
• Output Impedance: 50 ohm
– Key Features
• Dual-wavelength operation at 1.3 µm and 1.55 µm for standard telecommunications bands
• High-speed electrical output at 2.4 GB/s supports real-time signal analysis
• 50 ohm output impedance ensures compatibility with standard test equipment and instrumentation
• Handles signals up to +3 dB input power
• Used units are fully operational with normal cosmetic wear
– Typical Applications
• Optical signal characterization in long-haul and metro telecommunications networks
• Real-time monitoring of optical communication system performance
• Signal parameter measurement during system validation and troubleshooting
• Integration into automated test systems for optical transceiver evaluation
– Compatibility & Integration
The AQ5524B accepts optical input at standard telecommunications wavelengths—1.3 µm and 1.55 µm—and outputs a 2.4 GB/s electrical signal across a 50 ohm interface. This electrical output directly interfaces with standard oscilloscopes, bit-error-rate testers, and other 50 ohm measurement instruments commonly deployed in optical communication test labs.
