The Delta 9059 is an environmental test chamber designed for precise temperature and humidity testing applications. It is suitable for use in research laboratories, quality control, product testing, and storage/shelf-life determination scenarios where controlled environmental conditions are critical. The unit features a double-walled construction with stainless steel and aluminum components, and an epoxy-coated aluminum liner for efficient thermal management and reduced energy consumption. The Delta 9059 is equipped with a 9010 digital controller that allows for programmable temperature and time cycles, with a high degree of accuracy and repeatability.
### Technical Specifications
* **Model:** 9059
* **Manufacturer:** Delta Design
* **Test Volume:** 1.85 cubic feet (52.4 liters)
* **Internal Dimensions:** 11″ H x 19.5″ W x 15″ D
* **Overall Dimensions:** 17.25″ H x 32″ W x 25″ D
* **Temperature Range:** -73°C to +315°C (-100°F to +600°F)
* With optional LN2 cooling: -184°C (-300°F)
* **Temperature Accuracy (Setpoint to Actual):** ±1.0°C
* **Temperature Deviation (After Stabilization):** ±0.1°C
* **Repeatability:** ±0.25°C
* **Line Voltage Stabilization:** ±0.25°C for 105-125VAC or 220-240VAC line voltage change
* **Temperature Resolution:** 0.1°C
* **Setpoint Range:** -184°C to +135°C
* **Humidity Range:** 10% to 95%
* **Humidity Accuracy:** Not specified in available documentation.
* **Heating Rate:** 10°C / Minute
* **Cool Down Rate:** 22°C / Minute
* **LCO2 Consumption:** 9.62 lbs/hr at -53°C (-65°F)
* **Air Circulation:** Horizontal Air Flow Pattern
* **Controller:** 9010 Digital Controller
* Programmable cycles: Up to 9,999 repetitions
* Program step parameters: Temperature, time, and rate of change
* Soak time: 1 minute to 99 hours, 59 minutes
* Rate of change: 99.9°/minute maximum
* Process deviation limits: 2° to 99.9° or no limits
* **Over-Temperature Protection:** Adjustable
* **Power Requirements:**
* 120 VAC, 50 or 60 Hz, single phase, 1800W
* 208 VAC, 50 or 60 Hz, three wire, single phase, 1800W
* 208 VAC, 50 or 60 Hz, four wire, single phase, 1800W
* 240 VAC, 50 or 60 Hz, single phase, 1800W
* **Net Weight (Approx):** 98 Lbs (44.5 Kg)
* **Construction:** Double-walled, stainless steel and aluminum components, non-porous epoxy-coated aluminum liner
* **Access Port:** One 1-1/4” diameter access port on the left side
* **Certifications:** UL and FCC approved, CE and CSA certified
### Interfaces and Connectivity
* **Computer and Data Acquisition Systems:** Compatible for data logging and information retrieval
### Physical Characteristics
* **Frame and Fan Blade Material:** Meets UL 94V-0 flammability rating (Applies to Delta fans in general, specific material for 9059 not detailed)
### Compatibility
* **Accessories:** Compatible with accessories such as dehumidifier, lightning unit, RFI filter, aspiration and condensation protection unit
### Additional Features
* **Safety Features:** Alarm system, visual indicator light, over-temperature situation shutdown, power loss shutdown
* **Interior:** Features removable shelving
* **Cooling Medium:** Standard chamber coolant is 1050 psi LCO2; temperature expandable to –184°C utilizing optional LN2 cooling
