The Fujikura FAT-04 Fiber Arrangement Tool is a precision instrument that organizes individual optical fibers into temporary ribbon configurations for mass fusion splicing. By aligning up to 12 fibers in a linear arrangement, the tool reduces splicing errors and streamlines workflow efficiency during fiber optic network deployment and maintenance operations.
## Technical Specifications
• Fiber arrangement capacity: up to 12 fibers
• Applicable fiber type: silica glass fiber
• Coating diameter: 250 µm
• Coating material: UV-cured resin compatible
• Bundled fiber length: approximately 200 mm
• Arrangement method: guide slit linear travel
• Dimensions: 300 mm (L) × 90 mm (W) × 40 mm (H)
• Weight: 350 g
## Key Features
• Guide slit mechanism for controlled linear fiber positioning
• Paste applicator block (PAB-01) for adhesive application
• Retaining clips (CLP-02, qty. 2) secure fiber bundles during arrangement
• Ribbon-forming adhesive (FAA-03, 130 ml) included for ribbon bonding
• Consumable sponge pads and cotton swabs provided for preparation and cleanup
## Standard Package Contents
• Main body (1 pc.)
• Paste applicator block PAB-01 (1 pc.)
• Clips CLP-02 (2 pcs.)
• Ribbon-forming adhesive FAA-03 (130 ml bottle, 1 pc.)
• Sponge pads SP/SP-1 (125 blocks)
• Cotton swabs FM-225 (100 pcs.)
• Instruction manual
## Compatibility & Integration
The FAT-04 operates with 250 µm coated optical fibers and integrates into mass fusion splicing workflows. Optional fiber holders accommodate fiber counts from 2 to 12, enabling configuration flexibility. Replacement adhesive (FAA-03) is available in multi-pack sets for extended production runs.
