A trusted, global high-quality company with a long-standing
commitment to customers and continuous technological
innovation
► The newest oscilloscope portfolio from 60 MHz to 16 GHz
► In-house ASICs developed for the world’s most responsive
oscilloscopes
► Frontend technology development for pristine signal integrity
► 18-bit architecture with HD mode for the highest resolution
► Digital triggers for the world’s most sensitive event isolation
► Superior user interface and front panel that streamlines
workflows
Evolution in speed: Quick acquisitions with multiple channels,
math functions and seamless spectrum measurements for
minimal blind time with 21 ns rearm
► Unleash comprehensive spectrum analysis: Fast and pristine
spectrum analysis and ability to run up to four analyses
simultaneously
► Extensive memory capacity: Benefit from the deepest standard
memory and up to 1 million waveform segments
► Precise in-event detection: Our digital trigger is flawless at
18-bit HD resolution with adjustable sensitivity for accurate
triggering
► Uncompromised performance: A low noise floor and the largest
vertical offset range of ±5 V at 0.5 mV/div for exceptional signal
fidelity
► Setting new sensitivity standards: the industry most sensitive
trigger down to 0.0001 div
► Leading trigger jitter performance: Best-in-class trigger jitter of
less than 1 ps
MXO 5 series oscilloscopes incorporate a 12-bit A/D converter on all input channels. The 4096 quantization levels
deliver precise vertical resolution at all sampling rates for
uncompromising capture of signal details. The 18-bit architecture with HD mode also enhances the ADC resolution.
The MXO 5 series has up to eight channels with 12 bit precision and an uncompromised sampling rate.
Vertical resolution enhancement averages adjacent samples and reduces the sample rate, leading to waveform
issues such as aliasing. The MXO 5 HD mode in the hardware uses a moving average filter to remove aliasing. The
HD samples are then fed into the triggering system, making high resolution, low noise signals available for precise
triggering.
The MXO 5 series oscilloscope has outstanding sensitivity down to 500 µV/div without any unexpected reductions
in bandwidth. The offset of ±2 V on 50 Ω coupling and
±5 V on 1 MΩ coupling let you easily place the signal at
the center of the screen to examine DC noise and ripple.
The oscilloscope must have low noise levels to accurately
quantify small signals.
