The 3M Photodyne 17XTA is a handheld optical power meter for testing and troubleshooting fiber optic networks across single-mode and multimode installations. It delivers measurement capability from -73 dBm to +5 dBm with dynamic range extending to +20 dBm for high-performance applications. The instrument operates at four standard telecom wavelengths: 820 nm, 880 nm, 1300 nm, and 1550 nm, making it suitable for diverse network environments and analog systems requiring precision optical power assessment.
Technical Specifications
• Wavelengths: 820/880/1300/1550 nm
• Measurement Range: -73 dBm to +5 dBm
• Dynamic Range: Up to +20 dBm for high-performance applications
• Accuracy: Higher than previous generation units
• Optical Connector: 2.5 mm connector adapters
• Form Factor: Handheld
– Key Features
• Expanded dynamic range accommodates both standard and high-performance optical signals
• Improved accuracy over earlier models
• Dual-fiber compatibility eliminates need for separate instruments
• Compact handheld design enables field deployment and rapid troubleshooting
– Typical Applications
• LAN commissioning and link validation
• SONET and ATM digital system testing
• Analog cable television systems
• Erbium-doped amplifier characterization
• Network maintenance and restoration
• Engineering and field testing
– Compatibility & Integration
Designed for paired operation with the Photodyne 7XT Light Source, enabling complete bi-directional link characterization. Accepts 2.5 mm optical connector adapters for standard telecom interfaces.
