The Agilent/Keysight 08780-67003 is a calibration kit engineered for RF and microwave test and measurement applications. It delivers traceable standards essential for characterizing and correcting systematic errors in vector network analyzers and high-frequency test equipment, ensuring measurement accuracy and reliability across demanding laboratory and systems integration environments.
Technical Specifications
The kit comprises precision mechanical standards designed to support established calibration methodologies. Components typically include shorts, opens, loads, and airlines for TRL (Thru-Reflect-Line) calibration workflows. Standard RF/microwave connector interfaces such as 3.5 mm, 2.4 mm, or 2.92 mm are generally supported, enabling integration with industry-standard test ports.
– Key Features
• Traceable calibration standards for systematic error correction
• Precision mechanical construction for sustained measurement integrity
• Support for both SOLT (Short-Open-Load-Thru) and TRL calibration techniques
• Designed for laboratory and production test environments
– Typical Applications
The 08780-67003 is specified for calibration of RF and microwave characterization systems where measurement traceability is required. Primary use includes network analyzer calibration, reflection coefficient measurements, and S-parameter verification across RF and microwave frequency ranges.
– Compatibility & Integration
This kit is designed for use with Keysight’s PNA and PNA-L series network analyzers, as well as general RF and microwave measurement instrumentation. The precision mechanical standards ensure compatibility with systems requiring traceable calibration standards and error correction workflows in RF and microwave testing environments.
