The Agilent/Keysight 10466A is a C-size VXI switching module that implements a 4×64 two-wire matrix for precision signal routing in test systems. It switches both high and low sides at each crosspoint using latching armature relays, delivering cost-effective matrix expansion within complex measurement setups. The module shares its switch card architecture with the E1465A and E1467A, with terminal block configuration determining the specific matrix topology. Rows and columns can be daisy-chained across multiple modules to build larger matrices—a fully populated E1401B 13-slot mainframe supports up to 3072 two-wire crosspoints. Four interconnected 10466A modules create a 4×256 matrix using standard expansion cables.
Technical Specifications
Matrix Configuration
• Type: 4×64 two-wire switching matrix
• Relay Type: Latching armature relays
• Crosspoint Switching: Both high and low sides per crosspoint
Electrical Ratings
• Maximum Voltage: 200 V DC, 170 V AC RMS, 238 V peak-to-peak
• Maximum Current: 1 A DC, 1 A AC peak per channel
• Maximum Power: 30 W per channel, 62.5 VA per module (resistive load)
• Closed Channel Resistance: <4.0 Ω typical (worst case), <1.8 Ω (best case), 10⁸ Ω (≤40 °C, ≤95% RH), >10⁹ Ω (≤25 °C, ≤40% RH)
Performance
• Minimum Bandwidth (–3 dB, Zₗ = Zₓ = 50 Ω): 10 MHz
• Crosstalk (worst path): –66 dB closed-to-closed at <10 kHz; –45 dB closed-to-closed at <100 kHz; –29 dB closed-to-closed at <1 MHz
– Key Features
• Terminal block swapping enables topology reconfiguration without hardware changes
• Daisy-chain expansion via interconnection cables for matrix scaling
• Low on-resistance and excellent insulation performance for signal integrity
• Low thermal offset suitable for precision analog applications
– Typical Applications
• High-density switching matrices for automated test equipment
• Multi-channel signal routing and multiplexing
• Component characterization and validation test stands
• Large-scale measurement systems requiring configurable switch topologies
– Compatibility & Integration
The 10466A integrates into VXI mainframes and shares switch card architecture with the E1465A and E1467A modules. Expansion requires daisy-chain cables (e.g., E1466-80002). The E1467A with expansion terminal block options (201/211) and Z2220A series cables offers an alternative 8×32 matrix configuration with faster access and simplified cable management.
