The Agilent/Keysight 16603A is an accessory module designed to expand the measurement and analysis capabilities of compatible logic analyzer mainframes. It augments digital circuit analysis functionality for engineers and technicians engaged in design, debugging, and testing of digital systems.
Technical Specifications
The 16603A integrates with Agilent/Keysight logic analyzer systems to provide enhanced measurement capabilities. Host systems support state analysis with clock rates up to 700 MHz and data rates up to 1.4 Gb/s, with alternative configurations offering state analysis up to 100 MHz and memory depths of 32k samples per channel. Timing analysis extends from conventional operation up to 2.5 GHz/5.0 GHz (full-/half-channel) to high-resolution timing zoom capabilities up to 12.5 GHz with 80 ps resolution, with alternative series supporting timing resolution to 2 ns. Memory depth configurations range from 2 Mb standard up to 128 Mb optional in some series. Advanced triggering includes up to 1.4 GHz trigger sequencer with multi-level trigger sequencing.
– Key Features
• Input voltage threshold levels adjustable across TTL, 3-state TTL/3.3V, 3-state TTL/CMOS, ECL/PECL/LVPECL, and user-defined options with 10 mV increments
• Support for single-ended and differential probes
• Signal integrity monitoring with simultaneous eye diagrams across all channels
– Typical Applications
Ideal for digital system design verification, protocol debugging, and signal integrity analysis in complex digital circuits requiring extended measurement bandwidth and deep memory capture.
– Compatibility & Integration
The 16603A is compatible with Agilent/Keysight 16900, 16700, and 16500 series mainframes and modules. Integration includes GPIB (HP-IB) for remote control and data transfer, USB 3.0 ports for fast data transfer and storage, LAN connectivity, and RS-232-C serial interface.
