The Agilent/Keysight 86111U is a dual-channel optical module for precise analysis of optical signals in the 750-860 nm wavelength range. Operating at up to 15 GHz bandwidth, it characterizes high-speed optical signals in research, development, and manufacturing environments. Dual channels enable simultaneous measurement of multiple optical paths, improving test throughput over sequential analysis. The module integrates with Agilent/Keysight 86100A/B/C Infiniium DCA/DCA-J mainframes.
Technical Specifications
• Bandwidth: Up to 15 GHz
• Wavelength Range: 750-860 nm
• Channels: Dual
• Characteristic RMS Noise: 14 µW (at 15 GHz bandwidth)
• Maximum Average Input Power: 2 mW
• Fiber Compatibility: 62.5/125 µm
• Reference Receiver Capability: 1.250/2.488 Gb/s or 2.488/3.125 Gb/s data rates
– Key Features
• Simultaneous dual-channel measurement reduces testing time for parallel optical components
• 15 GHz bandwidth supports high-speed optical signal characterization
• Optimized for 750-860 nm spectral range applications
• Direct compatibility with 86100 series mainframes for integrated measurement systems
– Typical Applications
• Multi-channel optical signal analysis
• High-speed optical transceiver characterization
• Parallel optic device testing
– Compatibility & Integration
Designed for Keysight 86100A/B/C Infiniium DCA and DCA-J mainframes.
