The Fluke 6060A is a synthesized RF signal generator delivering precision frequency generation from 10 kHz to 520 MHz with 10 Hz resolution. Built around an internal 10 MHz crystal reference, this fully programmable instrument combines front-panel interactivity with optional IEEE-488 remote control for laboratory and production test environments.
Technical Specifications
Frequency & Output
• Frequency range: 10 kHz to 520 MHz
• Resolution: 10 Hz steps
• Output level: +13 dBm to −137 dBm in 0.1 dB increments
• Amplitude accuracy: ±1 dB
• Reference: Internal 10 MHz crystal oscillator; external 10 MHz timebase supported
Modulation Capability
• Modes: AM, FM, or combination with external sources; modulation can be disabled
• AM depth: 0 to 99% in 1% steps; 20 Hz to 30 kHz bandwidth (3 dB); incidental FM <0.3fm at 30% AM
• FM deviation: 100 Hz to 99.9 kHz across three ranges with 3-digit resolution; maximum deviation constrained by frequency and bandwidth rules; incidental AM <1% at 1 kHz rate
• Internal oscillators: 400 Hz and 1 kHz (±3% for 20–30 °C; ±0.1% per °C beyond range)
• External modulation: ±5 V maximum; 1 Vpeak = indicated modulation index; 600 Ω nominal input impedance (560 Ω with both AM and FM external)
Spectral Purity (CW)
• Spurious: 10 kHz offset)
• Fixed frequency spurs: <−60 dBc or <−140 dBm (whichever is larger)
• Harmonics: <−30 dBc
• SSB phase noise: −113 dBc/Hz at 20 kHz offset from 500 MHz carrier
• Residual FM: <13 Hz (0.3–3 kHz band, 245–512 MHz); <27 Hz elsewhere; <30 Hz (0.05–15 kHz band, 245–512 MHz); <60 Hz elsewhere
• Residual AM: <−60 dBc (0.05–15 kHz band)
– Key Features
• Synthesized architecture ensures frequency stability and precise tuning
• Independent AM and FM modulation with internal or external sources
• Optional IEEE-488 interface (Option 488) for remote programming and control
• Optional rear panel RF output and modulation input connectors (Option 830)
– Typical Applications
RF component and system testing including filters, amplifiers, mixers, and radio receivers requiring modulated or CW signals across UHF and lower VHF bands.
– Compatibility & Integration
IEEE-488 interface option enables integration into automated test systems. External modulation inputs accept standard ±5 V signals. Crystal reference allows synchronization with external 10 MHz standards.
