The JDS Uniphase MAPB+1E-Z003 is a broadband optical source module engineered for C-band testing and measurement applications in optical communication systems. This cassette-based instrument delivers configurable output power across the 1527 to 1568 nm wavelength range with exceptional stability and isolation characteristics. Available in 20 mW, 50 mW, and 100 mW configurations, the module integrates into the MAP platform’s hot-swappable architecture for flexible instrumentation deployment.
## Technical Specifications
• **Wavelength Range:** 1527 to 1568 nm (C-band)
• **Output Power Options:** 20 mW, 50 mW, or 100 mW at 1550 nm (23 °C, post one-hour warm-up)
• **Spectral Gain Flatness:** 1.6 dB maximum (1529 to 1565 nm)
• **Output Power Stability:** 0.02 dB
• **Output Isolation:** 45 dB minimum
• **Operating Temperature:** 0 to 50 °C
• **Storage Temperature:** −30 to 60 °C
• **Humidity:** Maximum 95% RH non-condensing (0 to 45 °C)
• **Physical Dimensions:** 4.06 cm W × 13.24 cm H × 39.5 cm D
• **Weight:** 2.3 kg
## Key Features
• Configurable output power in three standard levels
• Flat spectral response across C-band operational window
• Dual remote control interfaces: RS-232 and GPIB
• Hot-swappable cassette design—no system power-down required for installation or removal
• Automatic cassette identification via dynamic MAP firmware
• Local control via 9-key keypad and color display on mainframe
## Typical Applications
Component and system characterization within optical networks. Suitable for broadband light source requirements in optical test environments.
## Compatibility & Integration
Designed for the JDS Uniphase MAP series mainframes: 19-inch 8-slot Master (MAP+2M00) or 9.5-inch 3-slot Benchtop (MAP+2B00). Integrates with over 15 instrumentation cassette types within the MAP ecosystem.
