The Rohde & Schwarz SMIQ06ATE is a vector signal generator purpose-built for automated test equipment (ATE) environments, delivering high-accuracy modulation signals across 300 kHz to 6.4 GHz. It employs DSP technology and a broadband I/Q modulator to generate digital modulation signals with excellent vector accuracy, alongside analog modulation capability. The instrument supports multiple digital radio protocols including IS-95 CDMA, W-CDMA, and 3GPP W-CDMA via optional modules. Full programmability via IEEE 488 remote control eliminates the need for manual front-panel operation, making it ideal for integrated ATE systems where rear-panel RF and LF connections streamline signal routing and test automation.
Technical Specifications
• Frequency Range: 300 kHz to 6.4 GHz
• Modulation: Digital modulation signals (DSP-based), analog modulation, and digital radio protocol support
• Modulator: Broadband I/Q with excellent vector accuracy
• Control Interface: IEEE 488 (fully programmable)
• Configuration: ATE-optimized; no manual front-panel display
• RF Output: Rear-panel connection
• LF Output: Available via optional module (SMIQB19)
– Key Features
• DSP-based signal generation ensures high accuracy and stability across the entire frequency range
• Broadband I/Q modulator delivers precise vector accuracy for demanding digital modulation applications
• Optional modulation standards modules (SMIQB42, SMIQB43, SMIQB45) support IS-95 CDMA, W-CDMA, and 3GPP W-CDMA
• Rear-panel connectivity optimizes ATE rack integration and simplifies signal distribution
• Extensible architecture accommodates optional data generators, fading simulators, noise/distortion simulation, and arbitrary waveform generation
– Typical Applications
• Automated test systems for digital wireless devices and base-station equipment
• Multi-protocol signal generation for CDMA and WCDMA transceiver validation
• High-volume manufacturing test of RF/microwave modules requiring stable, repeatable stimulus signals
– Compatibility & Integration
The SMIQ06ATE maintains functional and specification parity with the SMIQ06B, with design optimizations for ATE deployment. Optional modules expand capabilities to include fading simulation, bit error rate testing, dynamic fading, and low-ACP filtering.
