The Wandel & Goltermann WG ANT-20E Advanced Network Tester is a sophisticated instrument engineered for in-depth analysis, troubleshooting, and performance verification of complex network infrastructures. It delivers protocol analysis, performance benchmarking, and fault diagnosis across a broad spectrum of network protocols and interfaces. The unit supports extensive protocol coverage relevant to telecommunications and data networking, with capabilities spanning multiple network layers.
Technical Specifications
• Device Type: Advanced Network Tester
• Primary Function: Network analysis, troubleshooting, and performance testing
• Protocol Support: Extensive telecommunications and data networking protocols (configuration and firmware dependent)
• Analysis Capabilities:
– Deep packet inspection and analysis across network layers
– Performance metrics including throughput, latency, jitter, and packet loss measurement
– Fault diagnosis and network anomaly isolation
• Data Capture: High-capacity data capture and storage for post-analysis
• User Interface: Technical interface combining physical controls and display for configuration and results presentation
– Key Features
• Modular interface card design for adaptation to specific network technologies
• Support for diverse physical interfaces including Ethernet variants, serial, optical, and telecommunications interfaces (E1/T1, E3/T3)
• Optional SFP/SFP+ module support for optical connectivity
• Management interfaces for remote operation and data transfer
• Portable or rack-mountable form factor configurations
– Typical Applications
• Enterprise network performance validation and optimization
• Network protocol compliance verification
• Multi-layer troubleshooting of complex network failures
• Laboratory and field network characterization
• Integration testing across heterogeneous network environments
– Compatibility & Integration
The modular architecture accommodates 10/100/1000Base-T Ethernet, fiber optic interfaces, serial connectivity, and telecommunications standards. Specific interface availability depends on installed modules and firmware version. The unit integrates with diverse network equipment through its flexible interface support.
