The Wavetek SAM1000 is a portable signal analysis meter that functions as an automatic network analyzer for characterizing high-frequency components and circuits. It measures signal levels across RF systems, performs signal quality assessment, and identifies faults in cable television networks. The instrument delivers 80 dB dynamic range with 0.1 dB resolution and ±1.5 dB accuracy, making it suitable for field troubleshooting and laboratory component testing in broadcasting, telecommunications, and CATV environments.
Technical Specifications
• Frequency range: 5 MHz to 1 GHz; 50 MHz to 557.875 MHz
• Measurement range: −30 dBmV to +60 dBmV
• Dynamic range: 80 dB
• Resolution: 0.1 dB
• Accuracy: ±1.5 dB
• Scan speed: 32 ms/point
• Input impedance: 75 ohms
• Synthesized tuning to 557 MHz
• Measurement units: dBmV, dBµV, dBm, dBµA, dBµW
• 4-position electronic attenuator
• Power supply: Rechargeable battery or AC adapter
• Operating temperature: 0°C to 50°C
• Storage temperature: −20°C to 70°C
• Dimensions: 8.5″ × 4.5″ × 2.5″
• Weight: 1.2 lbs
– Key Features
• Selective tuning distinguishes FM signals 600 kHz apart with 50 kHz @ 3 dB bandwidth
• Measures audio carrier presence in fields with video carriers 40 dB greater in amplitude
• Horizontal sync suppression measurement for scrambled channels
• Switch-selectable video/audio tuning
• LCD backlit display
• USB data transfer interface
• DB-37 connector for receiver and accessory attachment
• Internal signal generator and signal-chain analyzer
• Voltage and current control modules
• Logic-controlled VSWR calibrator
• Fast settling with multiple scan averaging
• Automatic self-alignment
– Typical Applications
• CATV system testing and troubleshooting
• RF component characterization (filters, amplifiers, switches, VCOs)
• Interconnect loss measurement
• S-parameter analysis
• Multi-port and polarimetric measurements
– Compatibility & Integration
USB interface enables data transfer to external systems. DB-37 connector accommodates field probes and measurement accessories for expanded analytical capability.
