The Adaptive Power Systems APS3015PG480 is a three-phase AC power source and frequency converter engineered to replicate utility grids across a wide range of voltages and frequencies. This 15 kVA unit delivers 5 kVA per phase and operates from 45 Hz to 500 Hz, making it suitable for international product testing, imported equipment operation, and specialized applications including military and avionics equipment requiring 400 Hz operation.
Technical Specifications
Power Output: 15 kVA total; 5 kVA per phase.
Output Voltage (Line-to-Neutral): 0–150 V (low range); 0–300 V (high range); optional 300 V/600 V L-N ranges available.
Output Voltage (Line-to-Line): Up to 260 V (low range); up to 520 V (high range).
Frequency Range: 45 Hz to 500 Hz with 0.1 Hz resolution (45–99.9 Hz) and 1 Hz resolution (100–500 Hz); ±0.2% accuracy.
Input Requirements: 208, 220, 240, 380, 415, or 480 VAC ±10%, three-phase, 47–63 Hz.
Performance: Output voltage distortion <1% THD (resistive load); crest factor ≥3:1; load regulation ±0.5%; efficiency ≥85% at full load.
Protection: Over-current, short-circuit, and over-temperature protection.
– Key Features
• Programmable voltage, frequency, and current limit settings via intuitive front panel controls
• Digital LED displays for frequency, voltage, current, power, and power factor per phase
• Three standard programmable memory locations; optional expansion to eight memories with five programmable steps each
• Auto Voltage Adjust feature for ±0.1 V regulation
• Optional GPIB or RS232 interfaces for remote control and expanded memory
• PLC remote interface supporting Run Programs P1, P2, P3, and Output On/Off command
– Physical Specifications
Dimensions: Approximately 33 in. H × 39 in. D × 24 in. W (839 mm × 980 mm × 600 mm).
Weight: Approximately 798 lbs (362 kg).
– Typical Applications
International product compliance testing, operation of imported equipment, military and avionics testing at 400 Hz, and grid simulation across variable voltage and frequency conditions.
– Compatibility & Integration
Supports GPIB and RS232 connectivity for automated test systems and PLC integration for multi-program sequencing.
