The Agilent/Keysight E1695A is a connectivity and signal access accessory engineered to extend the capability of Keysight logic analyzer platforms for digital systems testing and debugging. It facilitates reliable signal acquisition and accurate data capture essential for electronic troubleshooting and complex digital analysis workflows. The E1695A integrates within Keysight’s modular logic analysis ecosystem, supporting high-speed timing capture and deep memory operations across multiple measurement channels.
Technical Specifications
The E1695A is designed to interface with high-impedance probing solutions and flying-lead probe architectures used in modern logic analysis systems. Its construction meets the electrical and mechanical demands of high-speed digital signal acquisition with minimal impact on circuits under test.
– Key Features
• Accessory for Keysight 16900 Series modular logic analyzer mainframes
• Supports multiple probing configurations including high-impedance interposer probes and flying-lead probes
• Enables flexible signal access and connectivity across digital test points
• Maintains signal integrity during acquisition and analysis phases
– Typical Applications
• Digital circuit debugging and protocol analysis
• Timing validation and signal synchronization verification
• Complex multi-signal capture in embedded system development
• Signal integrity assessment in high-speed digital designs
• Post-acquisition waveform dissection and behavioral analysis
– Compatibility & Integration
The E1695A is purpose-built for integration with Keysight’s 16900 Series logic analyzers, which provide modular mainframes, configurable measurement channels, and advanced triggering and analysis tools. It works in conjunction with Keysight’s probe portfolio to optimize signal fidelity and measurement accuracy. Complete operating instructions and safety guidance are provided in the included User’s Manual.
