The Agilent/Keysight MSO9254A Mixed Signal Oscilloscope delivers 2.5 GHz analog bandwidth with integrated 4 analog and 16 digital channels, combining oscilloscope, logic analyzer, and protocol analyzer functionality in a single instrument. The MSO9254A captures complex mixed-signal designs with up to 20 GSa/s sample rate per channel and up to 1 Gpts upgradeable memory, enabling detailed signal acquisition and analysis across electronic design, validation, and troubleshooting workflows.
Technical Specifications
• Analog Bandwidth: 2.5 GHz (upgradable)
• Analog Channels: 4
• Digital Channels: 16
• Maximum Sample Rate: 20 GSa/s per channel (reduces when all four analog channels are active simultaneously)
• Standard Memory: 20 Mpts per channel
• Upgradeable Memory: Up to 1 Gpts (on 2 channels; reduces when all four analog channels are active)
• Waveform Acquisition Rate: Up to 250,000 waveforms per second
• Digital Memory (Logic Analyzer): 128 Mpts standard
• Display: 15″ XGA color TFT LCD with touch screen
• Dimensions: 9 inches deep (23 cm)
• Weight: 26 pounds (11.8 kg)
• Power Input: Autoranging 100–240 VAC
• Interfaces: USB 2.0, 100BASE-T LAN, RS-232 port; LXI Class C compliant
– Key Features
• InfiniiScan advanced triggering for precise signal capture
• Drag-and-drop measurements from measurement bar with cycle-specific analysis
• Up to five measurements across five different cycles with statistics display
• 16 fast, deep-memory digital channels for timing and data value observation
• Integrated protocol viewers for packet-level analysis and time correlation between protocol and physical layers
• Optional protocol support: I²C, SPI, RS-232/UART, CAN, LIN, FlexRay, JTAG, MIPI D-Phy, PCI Express, USB 2.0, 8B/10B, DDR 1/2/3, Ethernet, USB triggering and decode, SATA (1.5 Gbs) triggering and decode
• Optional jitter analysis applications: EZJIT, EZJIT Plus
• Optional DDR and LPDDR Compliance Test Application
– Typical Applications
Designed for complex signal analysis in digital design verification, embedded systems development, serial protocol debugging, power integrity assessment, and mixed-signal troubleshooting.
– Compatibility & Integration
Part of the Infiniium series. Combines oscilloscope, logic analyzer, and protocol analyzer capabilities into a unified 3-in-1 platform for time-correlated analog and digital signal observation.
