The Agilent/Keysight N4191A is an RF impedance analyzer for precise characterization of electronic components and materials across a broad frequency range. The instrument measures 14 impedance parameters with 4 1/2-digit resolution, supporting both spot and swept measurement modes. Built-in automatic error compensation and specially designed test fixtures deliver outstanding repeatability and accuracy, making it ideal for R&D and production environments.
Technical Specifications
Measurement Parameters & Resolution
• 14 parameters: impedance, resistance, admittance, conductance, inductance, capacitance, reflection coefficient
• Maximum parameter resolution: 4 1/2 digits
Frequency Range & Synthesis
• Test frequency: 1 MHz to 1000 MHz
• Internal synthesizer provides variable frequencies across UHF, VHF, and video bands
• Automatic sweep capability across full range
• Option 002: 100 Hz synthesizer resolution with 3 ppm accuracy
Measurement Ranges
• Impedance and Resistance: 100 mΩ to 20 kΩ
• Admittance: 100 µS to 10 S
• Conductance: 20 µS to 10 S
• Inductance: 0.1 nH to 5 mH
• Capacitance: 0.1 pF to 1 µF
• Reflection Coefficient: 0.0000 to ±1.0000
DC Bias Supply
• Voltage range: ±40 V in 10 mV steps
• Auto-sweep function included
Calibration & Error Correction
• Automatic error compensation referenced to 0, 50, and 75 Ω terminations
• 51 calibration frequencies including start/stop points
– Key Features
• Two front-panel settings stored in non-volatile memory for instant recall
• Spot measurement mode at specified frequency or DC bias
• Swept measurement capability (manual or automatic)
• HP-IB interface for standalone or integrated system operation
– Typical Applications
• Semiconductor characterization: C-V/G-V measurements, surface state evaluation, diode and transistor impedance
• Component testing: resonators, filters, magnetic and dielectric materials
• LCR evaluation of high-frequency chip and leaded components
• Communications component assessment: cables, connectors
– Compatibility & Integration
HP-IB interface enables integration with automated test systems. Available options include 100 Hz/200 Hz resolution synthesizer (Option 002), X-Y recorder output (Option 004), rack flange kit (Option 908), and front handle kit (Option 907).
