The HP/Agilent 4287A RF LCR Meter is a high-performance impedance measurement instrument operating from 1 MHz to 3 GHz with ±1.0% basic accuracy. It delivers rapid characterization of electronic components—particularly SMD inductors and EMI filters—using an advanced RF I-V measurement method that outperforms network analyzers for very small inductance detection. The 4287A measures impedance, admittance, inductance, capacitance, resistance, Q factor, and dissipation factor across a 200 mΩ to 3 kΩ range with nine millisecond per-point measurement time.
Technical Specifications
Measurement Parameters: |Z|, θz (rad/deg), |Y|, θy (rad/deg), X, G, B, Ls, Lp, Cs, Cp, Rs, Rp, Q, D. Four parameters simultaneously displayable.
Frequency Performance:
• Test frequency range: 1 MHz to 3 GHz
• Frequency resolution: 100 kHz
• Source frequency uncertainty: ±10 ppm (23 °C ±5 °C); ±20 ppm (5 °C to 40 °C)
Measurement Capability:
• Impedance range: 200 mΩ to 3 kΩ (@1 MHz, accuracy ≤10%)
• Basic accuracy: ±1.0%
• Measurement speed: 9 msec per point (maximum)
• Test signal level: 4.47 mVrms to 502 mVrms voltage (open); 0.0894 mArms to 10 mArms current (short); reduced levels above 1 GHz
• Output power: −40 dBm to 1 dBm (≤1 GHz); −40 dBm to 0 dBm (>1 GHz)
• Oscillator level: ≥−33 dBm
Calibration: Open/short/load/low-loss capacitor calibration with fixture electrical length compensation. Calibration performed at measurement plane using working load standards. Measurement accuracy reduced to half stated value if calibration performed outside 23 °C ±5 °C.
– Key Features
• RDC measurement function for contact verification (selectable)
• 1 m test cable with 3.5 mm female measurement terminal
• Opto-isolated handler interface for production integration
• 18 GB internal hard disk storage (Option 010)
• 1.44 MB floppy disk support
– Typical Applications
Production line testing, component characterization in R&D, manufacturing quality control, impedance verification of passive components at RF frequencies.
– Compatibility & Integration
Interfaces: GPIB, LAN (10base-T/100base-TX auto-switching), external keyboard/mouse, VGA output.
Power: 90–132 V or 198–264 V (auto-selected), 47–63 Hz.
Physical: 221.62 mm H × 425.6 mm W × 466.2 mm D; 36 lb.
