The Keysight N6776A is a 300 W DC power module engineered for integration into Keysight’s N6700 Low-Profile Modular Power System and N6705 DC Power Analyzer mainframes. This single-slot module delivers programmable voltage and current output with integrated measurement and protection capabilities, making it ideal for powering devices under test or supplying power to automatic test equipment system resources.
Technical Specifications
Output Ratings
• Voltage: 0 to 100 V
• Current: 0 to 3 A
• Power: 300 W maximum
Programming Accuracy (at 23°C ±5°C)
• Voltage: 0.1% + 100 mV
• Current: 0.15% + 30 mA
Ripple & Noise (20 Hz to 20 MHz)
• Constant voltage (rms): 45 mV
• Constant voltage (peak-to-peak): 18 mV
• Constant current (rms): 6 mA
– Key Features
• Programmable voltage and current control
• Built-in measurement and protection functions
• Economical pricing
• Optional high-speed test extensions (Option 054)
• Optional output disconnect and polarity reversal relays (Option 760)
• Optional output disconnect relays (Option 761)
– Typical Applications
The N6776A suits device characterization, component testing, and automated test environments where mid-range voltage and moderate current delivery are required. Its low output noise profile supports sensitive measurements on precision circuits.
– Compatibility & Integration
The module integrates into N6700 and N6705 mainframes, inheriting GPIB, LAN, USB, and LXI compliance from compatible systems. Physical dimensions are 425.6 mm × 194.7 mm (length × height). The product carries EU and UK Declarations of Conformity.
