The TEKTRONIX 80C02-CR is a high-performance optical sampling module delivering 30 GHz bandwidth for analysis of high-speed optical signals in telecommunications and datacom environments. Integrated clock recovery supports 9.953 Gb/s SONET/SDH standards, while the module accepts single-channel fiber input across the 1100 nm to 1650 nm wavelength range. This sampling head interfaces with Tektronix 8000 series oscilloscopes via the standard Acterna/W&G optical connector (FC/PC), enabling precise characterization of NRZ and RZ pulse formats, eye patterns, extinction ratio, Q-factor, and relaxation oscillation behavior.
Technical Specifications
• Bandwidth: 30 GHz
• Wavelength Range: 1100 nm to 1650 nm
• Fiber Input: 9/125 µm single-mode
• Optical Connector: FC/PC
• Filter Rate: 9.95 Gb/s
• Mask Test Sensitivity: −9 dBm at 9.953 Gbps
• Channels: 1
• Clock Recovery: Integrated CR option for 9.953 Gb/s telecom standards
– Key Features
• Supports 9.953 Gb/s (OC-192/STM-64), 10 Gb/s, and 40 Gb/s data rates
• Single-channel architecture optimized for high-speed optical signal acquisition
• Integrated clock recovery eliminates need for external synchronization at telecom standard rates
• FC/PC optical interface with universal test adapter compatibility
– Typical Applications
• High-speed optical communications testing
• Eye-pattern and pulse shape analysis
• Extinction ratio and Q-factor measurement
• NRZ and RZ pulse characterization
• Relaxation oscillation testing
• Optical conformance testing
• General-purpose high-performance optical component characterization
– Compatibility & Integration
Host instruments: Tektronix CSA8000 Communications Signal Analyzer, TDS8000 Sampling Oscilloscope, DSA8200 Sampling Oscilloscope, and 8000 Series Sampling Oscilloscopes. Universal Test Adapters sold separately.
