The ADLINK PXI-3488 is a PXI-based GPIB controller interface card that enables high-performance instrumentation control and communication across IEEE 488-compliant systems. This 3U Eurocard module manages up to 14 stand-alone instruments via IEEE 488 cables, delivering maximum data transfer rates of 1.5 MB/s through an on-board 1 KB FIFO buffer that bridges the performance gap between the slower GPIB bus and the faster PCI bus operating at 132 MB/s.
Technical Specifications
Interface & Standards
• IEEE 488 (GPIB) controller interface
• PXI specification Rev. 2.2 compliant
• CompactPCI compliant (PICMG 2.0 R3.0)
• PXI Bus: 32-bit 3.3 V or 5 V support
• Dimensions: 160 mm length × 100 mm height (excluding connectors)
Performance
• Maximum GPIB transfer rate: 1.5 MB/s
• On-board FIFO: 1 KB for read/write buffering
• Instrument control capacity: Up to 14 stand-alone instruments
Connectivity
• Front panel: 24-pin GPIB connector
• Rear panel: J1 IEC connectors to chassis backplane
– Key Features
• 1 KB FIFO buffer enables block transfer modes and optimized data flow
• Modular design with high shock resistance
• Performs reliably in harsh environment applications
• Interactive utility included for testing and diagnostics
– Typical Applications
Automated instrument control systems, test racks, and multi-instrument measurement setups requiring IEEE 488 protocol management within PXI chassis environments.
– Compatibility & Integration
Fully binary compatible with NI-488.2 driver APIs and industry-standard VISA Library. Supports programming in LabVIEW, LabWindows/CVI, VB, VC++, BCB, and Delphi. Compatible with Windows Vista, XP, 2000, and 2003 operating systems.
Status: End of Life
