The Fluke 8.5MM/1.2M Probe Scope is a specialized inspection accessory engineered for visual examination in confined and restricted-access environments. This detachable, semi-rigid probe features an 8.5 mm diameter camera head with dual-view imaging capability (front and side views) and extends inspection reach to 1.2 m. The elastomer-coated steel construction delivers flexible yet compliant handling characteristics suitable for demanding field operations across industrial, energy, transportation, and oil & gas sectors.
## Technical Specifications
• **Probe Diameter:** 8.5 mm
• **Probe Length:** 1.2 m (3.94 feet)
• **Conduit Diameter:** 6.1 mm
• **Conduit Construction:** Semi-rigid, elastomer-coated steel
• **Camera Configuration:** Dual view (front and side)
• **Field of View:** 62°
• **Depth of Field:** 35.5 mm (minimum) to 111.7 mm (maximum) — front and side imaging
• **Lighting:** Adjustable white LED
• **Digital Zoom:** 1x to 8x
• **Image Format:** JPG (still images)
• **Video Format:** AVI recording with MPEG compression
• **Waterproof Rating:** 2 psi maximum
• **Detachable:** Yes
## Key Features
• Dual-view camera provides simultaneous front and side visual inspection without articulation
• Flexible probe geometry navigates tight bends and constrained spaces
• Adjustable LED illumination compensates for variable ambient conditions
• Wide depth of field range (35.5 mm to 111.7 mm) accommodates near and distant inspection targets
• 8x digital zoom capability enables detailed examination from the camera head position
• Native JPG and AVI recording integrates with standard image and video workflows
## Typical Applications
• Machinery maintenance and quality control inspections
• Weld examination and structural damage assessment
• Hydraulic and pneumatic system inspection
• Electrical conduit and cable run verification
• Leak detection and fluid-based indicator inspection
• Foreign object debris (FOD) screening in confined geometries
• Pipe, hose, and equipment surface wear evaluation
## Compatibility & Integration
Designed exclusively for integration with Fluke DS701 and DS703 FC Videoscopes. Supports all videoscope functions except the Up is Up™ orientation feature. Probe detaches for independent storage and cleaning.
