The JDS Uniphase FBP-SE01 is a fiber optic inspection probe that delivers high-magnification visual examination of fiber connectors, bulkheads, and optical devices. Built around a 1/3-inch CMOS video camera with dual magnification (200x and 400x), the probe employs coaxial blue LED illumination—rated for over 100,000 hours—to resolve end-face geometry, cleanliness, and defects with precision. An in-probe focus mechanism and QuickCapture™ button enable rapid image acquisition. The probe connects via Hirose™ connector to T-BERD/MTS platforms or PC/laptops through USB, drawing power from the host display device or port.
## Technical Specifications
• **Camera:** 1/3-inch CMOS video sensor
• **Magnification:** 200x and 400x options
• **Field of View:** 550 μm (200x); 350 μm (400x)
• **Light Source:** Integrated blue coaxial LED, >100,000 hour lifetime
• **Focus:** Adjustable in-probe mechanism
• **Connector (Probe):** 4- or 6-pin Hirose™
• **Dimensions:** 46 × 43 × 140 mm
• **Weight:** 180 g
• **Power:** USB or display device
## Key Features
• Coaxial illumination for artifact-free end-face imaging
• Instant image capture with QuickCapture™ button
• Supports inspection of both male (patch cord) and female (bulkhead) interconnects
• Multi-fiber and ribbon array inspection on X- and Y-axis
• Extended LED lifespan minimizes source maintenance
## Typical Applications
• FC, SC, SC-APC, and LC connector inspection in bulkheads
• 2.5 mm and 1.25 mm patch cord connector examination
• Transceiver and optical device end-face analysis
• Network installation and maintenance verification
## Compatibility & Integration
The FBP-SE01 integrates with T-BERD/MTS test platforms and standard PC/laptop interfaces via USB. A full range of precision FBPT tips and adapters accommodate diverse connector geometries and inspection scenarios.
